10-Port Clear Multi-Tap Pre-Insulated Connector, 500 MCM – 4 AWG

Name: 10-Port Clear Multi-Tap Pre-Insulated Connector, 500 MCM - 4 AWG
Brand: Polaris
SKU: IPLD500-10C

Insulated Mechanical Connectors

#IPLD500-10C

Polaris Vision Tap Multi-Tap Connectors form secure connections between multiple conductors with a transparent rounded design and chemical-resistant insulation coating. Installs with a hex key and torque wrench, with no need for cover and taping.

Clear Exterior: Vision Tap transparent design lets users see their work to ensure ideal conductor placement and the most secure connection. Suitable for use on the line side of the service equipment as per the NEC article 230.46 requirement. Suitable for use on the line side of the service equipment as per the NEC article 230.46 requirement.
Dual-Sided Wire Entry: Form secure connections between 10 conductors quickly using the double-side entry ports sized for wires between 500 MCM and 4 AWG
Ergonomic Design: Rounded corners and a smooth exterior finish over the abrasion-resistant plastisol insulation make Polaris connectors comfortable to grip
Removable Plugs: Each port and set screw comes with a secure plug to prevent debris from entering the insulated connector
Parallel Rated: This connector is specifically designed and rated for parallel installation, providing a safe and secure way to handle larger projects

Product Information

Voltage Rating	600 V
Material	Aluminum
Finish	Plastisol Insulated
Color	Clear
Pack Qty	1
GTIN	662381996879
UPC	662381996879
EAN	662381996879
UNSPSC	39121409
Ul Standard	UL 486A/B
Wire Cable Class	Class B, Class C
Conductor Cu Size Range	500 MCM-4 AWG
Conductor Al Size Range	500 MCM-4 AWG
Conductor Type	Copper, Aluminum
Assortment	Clear Coated Pre-Insulated Connectors
