3/0 AWG 1/2” 2-Hole Copper Long Lug with Peep Hole – Orange

#L30NP

The POLARIS compression design creates a permanent, vibration-resistant connection that you can rely on with low contact resistance. Suitable for a wide range of applications, including power distribution, grounding and data transmission.

  • High conductivity copper tubing and corrosion resistant tin-plated finish
  • Marked with die index and color coded
  • Peep hole allows easy inspection of the termination
  • Flex rated for use with K, H, G, I, M and DLO cable
  • UL/cULus listed and rated for B/C class wire

Product Information

Voltage Rating 600V
Material Copper
Finish Tin Plated
GTIN 662381335937
UPC 662381335937
EAN 0662381335937
UNSPSC 39121405
Ul Standard UL 486A-486B, UL467
Barrel Inside Diameter 0.49
Barrel Outside Diameter 0.62
Wire Cable Class Class B, Class C
Conductor Type Copper
Tang Thickness 0.126
Tang Length 2.99
Hole Spacing 1.75
Wire Range 3/0 AWG
Assortment Copper Compression Terminations
Expanded Wire Range 3/0 AWG – 2 AWG
Die Color Code Orange
Mounting Bolt Size 1/2
Mounting Hole Diameter 0.51
Barrel Length 1

Resources

Documents

  • POL_L30NP_CMP_ProDraw_DIGITAL.pdf Download
  • POL_CU Installation Insert_CMP_InstInsert_PressReady.pdf Download
  • POL_Compression_CMP_CatBro_DIGITAL.pdf Download
  • POL_CUCompression_CMP_ProdInstall_Digital.pdf Download
  • POL_TERMLUGS_CMP_ProdSheet_DIGITAL.pdf Download
  • POL_TERMLUGS_CMP_ProdXRef_DIGITAL.pdf Download

Video resources
